Customizable PE Black And White Adhesive Protective Film For
Aluminum Sandwich Panel
Technical Data
Haoen’s ACP(aluminum composite panel) Protection Film acts as a
barrier of protection for your aluminum composite panel from
various elements.
It can effectively protect the surface of aluminum composite panels
from scratches, damage and contamination during transportation and
installation.
Usage | Provide a protective barrier to scratch, mark, damage and dirt at
the process of cutting, drilling, transportation and installation. |
Base Material | Polyethylene (PE) |
Glue | Water-based acrylic |
Color | Transparent, blue, white, black and white, green and so on. |
Thickness | 40-150 microns | Recommend Thickness | 80 microns |
Width | 100-1800 mm | Recommend Width | 1020 mm |
Length | 15-1000 m | Recommend Length | 500/700 m |
180 peel strength | 80-500 g/25mm | Widely used | 60/140/250/480 g/25mm |
Tensile Strength | Trasv> 8N/25mm
Longi> 15N/25mm |
Elongation | Trasv> 300%
Longi> 180% |
Print | Up to 3 colors |
Note:
1,The color can be customized according to your requirements.
2,logo can be printed on the film, the printing color is at most 3
colors.
3,The maximum width of 0.15mm thick film is 1250mm.
4,Our company can improve the aging resistance degree of the
original film according to the customer's requirement.
Product feature:
The high gloss polyethylene is used as the base material, attached with environment-friendly glue. It does not move glue, not
transformed and not fall off at a high temperature of 65℃.
Peeling force test : take a 180 degree peeling force test on the tension test machine,
measure three to five times, and take the average number as a reference.
Stickability performance test: easy to paste on the surface of the object, leave no residual glue after peeling off.
A. Bend 45 degrees, do not break, do not fall off.
B. Peel off the film after Pittsburgh film test , there is no residue glue left, no damage to the film .
UV-resistant degradation test: after 60 hours of 300 Watt UV-lamp irradiation at the temperature of 50℃, it doesn't crack or deform. And there is no residue glue left when peeling off .
Heat-resistant degradation test: At the temperature of 200℃ , it do not fall off within 3 minutes. There is no residue glue after peeling down. The surface will not
be corroded .
FAQ
1.Q:Are you a trading company or manufacturer?
A:We are a factory. Our factory is located in Wuxi, Jiangsu province.
2.Q: What are your main products?
A:Our main products are transparent film,white film ,blue film and
black&white film.It can protect numerous products to avoid
scratch, mark, damage and dirt at the process of bending, pressing,
roll forming, transportation and installation etc.
3.Q:Do you have a whole production line for protective film?
A:Yes,we have,such as :blowing mold,coating
,laminating,printing,slitting,etc.
4.Q:How can I know your product is good enough to meet our
requirements.
A:(a)Our company has been manufacturing protective films for more
than 8 years.
(b)We supply PE protective film for some top 10 aluminum or
stainless steel maker in china.
(c)Free sample for testing.
(d)Trained and professional technician team there ,after sales
service is offered.
5.Q:Do you accept OEM?
A:Yes,we do.We supply OEM service.
Contact us for more information and free samples!
